Description

ZL20-032102 4110000038180 EXTERNAL COVER PLATE TRANSMISSION4110000499 BYD4208

序号 名称 description 号码
1 螺母GB810－M20*1.5EpZn－8 NUT 4013000220
2 垫圈GB858－20 WASHER 4015000285
3 垫圈 ZL20-032011 20 WASHER 4110000038171
4 凸缘总成ZL20-030061X1 FLANGE 4110000499252
5 P轴承GB297-32207 BEARING 4021000167
6 输入轴 ZL20-032008 INPUT SHAFT 4110000038174
7 闷塞 ZL20-032009 9 PLUG 4110000038175
8 挡圈GB893.1-75-65Mn RETAINING RING 4015000014
9 滚动轴承GB276-6009 BALL BEARING 4021000010
10 齿轮 ZL20-032007X1 (Z = 33 ) GEAR 4110000038178
11 挡圈 ZL20-032101 RETAINING RING 4110000038179
12 外端盖 ZL20-032102 COVER PLATE 4110000038180
13 外摩擦片 1201-0007A FRICTION DISC 4110000038181
14 内摩擦片 ZL20-032103 FRICTION DISC 4110000038182
15 挡圈GB894.2-60-65Mn RETAINING RING 4015000284
16 弹簧座 ZL20-032110 SPRING SEAT 4110000038184
17 弹簧 ZL20-032108 SPRING 4110000038185
18 活塞 ZLZO-032106 CYLINDER PISTON 4110000038186
19 封油圈 ZL20-032107 SEALING RING 4110000038187
20 O形圈GB1235-60*3.1 O-RING 4030000638
21 离合器壳体总成 ZL20-032105 HOUSING 4110000038189
22 钢球5-GB/T308-2002 BALL 7200002550
23 阀座 ZL20-032109 SEAT 4110000038191
24 齿轮 ZL20-032010X1 ( Z = 46 ) GEAR 4110000038192
25 止动垫 ZL20-032006 SPACER 4110000038193
26 螺栓GB5783-M10*25-8.8 SCREW 4011001164
27 圆柱销 8m6×22 GB/T119-1986 Pin 4110000499253
28 轴套 ZL20-032004 BUSHING 4110000038196
29 内封油套 ZL20-032003 BUSHING 4110000038197
30 活塞环(Φ52)CA10-350914-A PISTON RING 4110000038198
31 轴端档板 Zl20-032002A COVER PLATE 4110000038199
32 止动垫 ZL20-032001 SPACER 4110000038203
33 螺栓GB5783-M8*20-8.8 BOLT 4011000723
