Description

JN3A 4130000912 BATTERY RELAY SDLG LG956 LG958 L933 L938F Loader part

LG958 2937001748:Electric system

1 红电瓶线护套 CABLE SLEEVE 26370002451
2 马达-充电线 BATTERY CABLE 29370017781
3 螺栓GB16674-M8*16EpZn-8.8 BOLT 4011000461
4 电瓶线A50*350 BATTERY CABLE 29370014291
5 电源开关K01K18-A BATTERY SWITCH 4130000427
6 电瓶线P50*150 BATTERY CABLE 29370014261
7 黑电瓶线护套 CABLE SLEEVE 26370002441
8 蓄电池6-QW-120B WET BATTERY 4130000057
(4130000057C)
(4130000057B) 6-QW-120B N 000002
9 蓄电池串联线 BATTERY CABLE 29370013101
10 电瓶线P15*1900 BATTERY CABLE 29370017801
11 电瓶线P15*1700 BATTERY CABLE 29370017811
12 走线胶套 RUBBER SLEEVE 29370017371
13 继电器保护盒 COVER 29370015301
14 螺钉GB818-M6*10EpZn-4.8 SCREW 4014000024
15 垫圈GB97.1-6EpZn-300HV WASHER 4015000207
16 继电器固定板 BRACKET 29370017351
17 CR板 RUBBER PLATE 29370017341
18 扎丝N90666101 CABLE TIE 4190001095
19 预热继电器V23132-B2002-X025 RELAY 4130000994
20 螺钉GB818-M6*16EpZn-4.8 SCREW 4014000026
21 螺母GB6170-M6EpZn-8 NUT 4013000028
22 接触器JCC100/1C24·48 RELAY 4130000962
23 螺钉GB818-M4*10EpZn-4.8 SCREW 4014000061
24 垫圈GB97.1-4EpZn-300HV WASHER 4015000135
25 扎丝LG13-ZS4*250 CABLE TIE 4190000020
26 管夹φ15 CLAMP 29370017311
27 双音盆形喇叭DL125-24V HORN 4130000009
28 螺栓GB16674-M6*10EpZn-8.8 BOLT 4011000152
29 插件支架 BRACKET 29370017391
30 管夹Φ25 CLAMP 29370018841
31 前左组合灯LFLDH4-24V LAMP 4130000542
32 前车架线束 WIRING HARNESS 29370017281
33 前右组合灯LFRDH4-24V LAMP 4130000543
34 扎丝LG13-ZS4*160 CABLE TIE 4190001839
35 隔膜式压力开关0166-40404-1-016 PRESSURE SWITCH 4130000329
36 支架 BRACKET 26370001072
37 螺栓GB16674-M10*16EpZn-8.8 BOLT 4011000488
38 管夹 CLAMP 26370001921
-4041002377 N 000003
39 管夹 CLAMP 29220009911
40 管夹Φ12 CLAMP 29370018651
41 支架 BRACKET 26370001172
42 螺栓GB16674-M8*35EpZn-8.8 BOLT 4011000161
43 螺母GB6170-M8EpZn-8 NUT 4013000033
44 后车架线束 WIRING HARNESS 29370017692
45 后尾灯LRHD-24V TAIL LIGHT 4130001134
46 蓄电池继电器024-1H2T-80A RELAY 4130000912
47 后大灯SPH4-1031 LAMP 4130000544
48 后罩线束 WIRING HARNESS 29370018131
49 工作灯148*86-H3-24V LAMP 4130001685
50 倒车蜂鸣器KSHM-12F4 BUZZER 4130000121
51 仪表台线束 WIRING HARNESS 29370017681
52 插件支架 BRACKET 29370017411
53 仪表盘总成Y958DC DISPLAY PANEL 29370017511
54 中间继电器024-1Z6GD2 RELAY 4130000869
55 电子油门踏板WL400244 ACCELERATOR PEDAL 4130001081
56 螺栓GB16674-M8*20EpZn-8.8 BOLT 4011000458
57 仪表台总成 INSTRUMENT PANEL 29370014601
58 侧边单框架JK931-01CKJ SWITCH PANEL 4130000498
59 盖板JK931-01GB COVER PLATE 4130000496
60 中间单框架JK931-01ZKJ SWITCH PANEL 4130000497
61 螺钉GB818-M5*12EpZn-4.8 SCREW 4014000048
62 垫圈GB97.1-5EpZn-300HV WASHER 4015000110
63 多态开关3735075-739 SWITCH 4130001087
-4130002655 Y 000001
64 手制动开关LA39-01Z BUTTON 4130000060
-4130001842 LA39-01Z N 000001
65 支板 BRACKET 29370017761
66 螺钉GB818-M3*10EpZn-4.8 SCREW 4014000267
67 垫圈GB97.1-3EpZn-300HV WASHER 4015000200
68 81针ECU线束 WIRING HARNESS 29370017521
69 支架 BRACKET 29370017741
70 螺栓GB5782-M8*120EpZn-8.8 SCREW 4011000697
71 螺栓GB16674-M12*25EpZn-8.8 BOLT 4011000560
72 垫圈GB97.1-8EpZn-300HV WASHER 4015000072
73 胶板 RUBBER PLATE 29370017791
74 卡子胶条 SEALING STRIP 29290009451
75 发动机线束3724815-1090 WIRING HARNESS 4130001088
-4130001900 Y 000001
76 发动机控制单元 3601115-98D-BF6M1013-21T2-1097 ENGINE CONTROL MODULE 4130001086
77 螺钉GB70.1-M6*25-8.8 SCREW 4014000174
78 防护管 PIPE 29430000581
