Description

Drive shaft 29080000051 29080007531 29080007521 SDLG LG958L Wheel Loader Part

1 螺栓GB5785-M12*1.25*50EpZn-8.8 BOLT 4011000431 GB5785-M12*1.25*50EpZn-8.8
2 垫圈GB93-12-65Mn SPRING WASHER 4015000026 GB93-12-65Mn
3 传动轴 PROPELLER SHAFT 29080007521 ZL50G1.5.2
4 中间支承 SUPPORT BEARING 29080000032 ZL50G.5.6
5 螺栓GB5785-M14*1.5*55EpZn-8.8 BOLT 4011000241 GB5785-M14*1.5*55EpZn-8.8
6 螺母GB889.2-M14*1.5EpZn-8 LOCK NUT 4013000073 GB889.2-M14*1.5EpZn-8
7 垫圈GB97.1-14EpZn-300HV WASHER 4015000177 GB97.1-14EpZn-300HV
8 中间传动轴 PROPELLER SHAFT 29080007531 ZL50G1.5.1
9 螺栓LG05-LS1/2＂-20UNF SCREW 4110000046
10 垫圈LG05-DQ1/2＂ WASHER 4015000202 LG05-DQ1/2＂
11 后传动轴 PROPELLER SHAFT 29080000051 ZL50G.5.4
12 支架 BRACKET 29080007851
13 螺栓GB5786-M8*1*30EpZn-8.8 BOLT 4011000684 GB5786-M8*1*30EpZn-8.8
14 螺母GB889.2-M8*1EpZn-8 LOCK NUT 4013000178 GB889.2-M8*1EpZn-8
15 垫圈GB97.1-8EpZn-300HV WASHER 4015000072 GB97.1-8EpZn-300HV
16 车速传感器支架 BRACKET 29080007791 1 轮胎GB2980-23.5-25 TIRE 4110000006
2 轮辋LG19.50/2.5-25 RIM 4190000237
3 轮边减速器 HUB REDUCTION 29070012881
4 制动盘 DISC BRAKE 29070000071
5 制动钳 BRAKE CALIPER 4120001739
6 磁性螺塞 PLUG 29070012481
7 后主传动总成 FINAL DRIVE 29090009481
8 后桥标牌 NAME PLATE 29090008851
9 铆钉GB827-3*5-BL2 RIVET 4019000012
10 透气嘴 NOZZLE 4110000818
11 后桥壳总成 REAR AXLE CASING 29090009381
12 O形圈LGB308-260*3.5 O-RING 4041000021
13 支承轴 SUPPORT SHAFT 29090000151
14 O形圈GB3452.1-160*5.30G O-RING 4030000021
15 密封盖 SEALING COVER 29090000101
16 轴套 SLEEVE 29090000112
17 衬垫 SHIM 29090000121
18 后桥支架 BRACKET 29090000091
19 垫块 BLOCK 29090000131
20 垫片 SHIM 29090000161
21 端盖 END PLATE 29090000141
22 螺栓GB5782-M12*50EpZn-8.8 BOLT 4011000064
23 垫圈GB93-12-65Mn SPRING WASHER 4015000026
24 螺栓GB5785-M20*1.5*90EpZn-8.8 BOLT 4011000113
25 垫圈GB93-20-65Mn SPRING WASHER 4015000030
26 螺母GB889.2-M30*2EpZn-8 LOCK NUT 4013000064
27 螺栓 SCREW 29090007982
28 螺栓GB5783-M12*35EpZn-8.8 BOLT 4011000090
29 螺栓GB5786-M16*1.5*50EpZn-8.8 BOLT 4011000244
30 垫圈GB93-16-65Mn SPRING WASHER 4015000098
31 螺栓 BOLT 29070000101
32 螺栓GB5786-M20*1.5*50EpZn-8.8 BOLT 4011000130
