Description

4110001903126 Bearing Seat G9190 G9180 Grader parts

4110001903:Tandem drive(320307)
1 螺塞M24*1.5 75 500 197 PLUG 4110001903049
2 组合密封垫24 53 200 005 SEALING WASHER 4110001903048
3 平衡箱组件90 510 013 TANDEM DRIVE 4110001903111
4 轴承33113 54 100 059 BEARING 4110001903112
5 链轮与轴组件85 513 031 CHAIN GEAR 4110001903113
6 油封FB115*140*12 53 100 029 SEALING RING 4110001903114
7 O型密封圈475*7 53 000 055 O-RING 4110001903115
8 连接盘85 513 019 CONNECTION FLANGE 4110001903116
9 垫圈85 513 043 WASHER 4110001903117
10 轴承32018 54 100 002 BEARING 4110001903118
11 油封FB100*125*12 53 100 038 SEALING RING 4110001903119
12 隔套85 513 042 SPACER SLEEVE 4110001903120
-28100006661 N 000002
13 螺栓M8*25 50 008 006 SCREW 4110001903155
14 油封座85 513 034 SEAT 4110001903122
15 梯子85 865 005 STEP 4110001903123
16 螺栓M14*1.5*55 50 011 011 SCREW 4110001903028
17 O型密封圈135*3.1 53 000 013 O-RING 4110001903125
18 轴承座85 513 015 BEARING SEAT 4110001903126
19 垫圈12 52 020 004 WASHER 4110001903031
20 螺栓M12*40 50 009 021 SCREW 4110001903128
21 油杯M10*1 56 300 006 LUBRICATING NIPPLE 4110001903129
22 支撑套85 763 021 SLEEVE 4110001903161
23 O型密封圈260*5.7 53 000 016 O-RING 4110001903131
24 盖85 513 013 COVER 4110001903132
25 垫圈8 52 020 002 WASHER 4110001903019
26 螺栓M8*20 50 009 007 SCREW 4110001903134
27 双排链轮85 513 022 CHAIN GEAR 4110001903135
28 滚子链32B*1-54 55 410 003 ROLLER 4110001903136
29 轴承座85 513 027 BEARING SEAT 4110001903137
30 轴承22319C 54 900 008 BEARING 4110001903138
31 螺钉M16*50 50 120 013 SCREW 4110001903154
32 压板85 513 021 ANCHOR PLATE 4110001903140
33 盖85 513 025 COVER 4110001903141
34 螺栓M12*35 50 120 004 SCREW 4110001903063
35 螺栓M12*30 50 009 058 SCREW 4110001903143
36 螺钉M16*40 50 120 010 SCREW 4110001903144
37 垫圈16 52 020 006 WASHER 4110001903004
38 螺栓M14*1.5*40 50 012 019 SCREW 4110001903146
39 垫圈14 52 020 005 WASHER 4110001903029
40 螺栓M16*32 50 009 030 SCREW 4110001903148
41 通气塞Z1/8″56 100 001 AIR VENT COCK 4110001903149
42 盖组件85 513 014 COVER 4110001903150
43 紧定螺钉M8*2050193001 SCREW 4110001903151
44 盖85 513 039 COVER 4110001903152
45 链轮与轴组件85 513 030 CHAIN GEAR 4110001903153
46 调整垫片85 513 045 SHIM 4110001903158
47 调整垫片85 513 046 SHIM 4110001903159
48 调整垫片85 513 047 SHIM 4110001903160
49 调整垫片85 513 048 SHIM 4110001903162
50 调整垫片85 513 049 SHIM 4110001903163
51 调整垫片85 513 050 SHIM 4110001903164
4110001903:Tandem drive
1 螺塞M24*1.5 75 500 197 PLUG 4110001903049
2 组合垫圈24 53 200 005 SEALING WASHER 4110001903110
3 平衡箱组件90 510 014 TANDEM DRIVE 4110001903156
4 轴承33113 54 100 059 BEARING 4110001903112
5 链轮与轴组件85 513 030 CHAIN GEAR 4110001903153
6 油封FB115*140*12 53 100 029 SEALING RING 4110001903114
7 O型密封圈475*7 53 000 055 O-RING 4110001903115
8 连接盘85 513 019 CONNECTION FLANGE 4110001903116
9 垫圈85 513 043 WASHER 4110001903117
10 轴承32018 54 100 002 BEARING 4110001903118
11 油封FB100*125*12 53 100 038 SEALING RING 4110001903119
12 隔套85 513 042 SPACER SLEEVE 4110001903120
-28100006661 N 000002
13 螺栓M8*25 50 008 006 SCREW 4110001903155
14 油封座85 513 034 SEAT 4110001903122
15 梯子85 865 005 STEP 4110001903123
16 螺栓M14*1.5*55 50 011 011 SCREW 4110001903028
17 O型密封圈135*3.1 53 000 013 O-RING 4110001903125
18 轴承座85 513 015 BEARING SEAT 4110001903126
19 垫圈12 52 020 004 WASHER 4110001903031
20 螺栓M12*40 50 009 021 SCREW 4110001903128
21 油杯M10*1 56 300 006 LUBRICATING NIPPLE 4110001903129
22 支撑套85 763 021 SLEEVE 4110001903161
23 O型密封圈260*5.7 53 000 016 O-RING 4110001903131
24 盖85 513 013 COVER 4110001903132
25 垫圈8 52 020 002 WASHER 4110001903019
26 螺栓M8*20 50 009 007 SCREW 4110001903134
27 双排链轮85 513 022 CHAIN GEAR 4110001903135
28 滚子链32B*1-54 55 410 003 ROLLER 4110001903136
29 轴承座85 513 027 BEARING SEAT 4110001903137
30 轴承22319C 54 900 008 BEARING 4110001903138
31 螺钉M16*50 50 120 013 SCREW 4110001903154
32 压板85 513 021 ANCHOR PLATE 4110001903140
33 盖85 513 025 COVER 4110001903141
34 螺栓M12*35 50 120 004 SCREW 4110001903063
35 螺栓M12*30 50 009 058 SCREW 4110001903143
36 螺钉M16*40 50 120 010 SCREW 4110001903144
37 垫圈16 52 020 006 WASHER 4110001903004
38 螺栓M14*1.5*40 50 012 019 SCREW 4110001903146
39 垫圈14 52 020 005 WASHER 4110001903029
40 螺栓M16*32 50 009 030 SCREW 4110001903148
41 通气塞Z1/8″56 100 001 AIR VENT COCK 4110001903149
42 盖组件85 513 014 COVER 4110001903150
43 紧定螺钉M8*2050193001 SCREW 4110001903151
44 盖85 513 039 COVER 4110001903152
45 链轮与轴组件85 513 031 CHAIN GEAR 4110001903113
46 调整垫片85 513 045 SHIM 4110001903158
47 调整垫片85 513 046 SHIM 4110001903159
48 调整垫片85 513 047 SHIM 4110001903160
49 调整垫片85 513 048 SHIM 4110001903162
50 调整垫片85 513 049 SHIM 4110001903163
51 调整垫片85 513 050 SHIM 4110001903164
