Description

408104 03A0016 SP105374 7200000183 W040101820 00A0041 Caliper Joint for Wheel Loader

1 吊环螺钉13020212 SCREW 4110001525004
2 气缸盖螺栓13037377 SCREW 4110000846113
3 气缸盖螺栓13037379 SCREW 4110000846115
4 气缸盖螺栓13037378 SCREW 4110000846114
5 机体分总成13050827 CYLINDER BLOCK 4110001031048
6 圆柱销Q5210818 01105156 PIN 4110000054313
7 圆柱销13033415 PIN 4110000846146
8 平垫圈Q40110 01152752 WASHER 4110000054227
9 防松螺母Q33210 01321459 NUT 4110000054332
10 弹性圆柱销Q5280408 01115413 SPRING PIN 4110000054028
11 密封垫圈01118707 SEALING RING 4110000054192
12 六角头螺塞Q617B16 01151453 PLUG 4110000054151
13 停油拉线支架13022903 BRACKET 4110000054291
14 垫片12167427 WASHER 4110000054042
15 六角螺母Q360B06 90012700001 NUT 4110000054140
16 套管12159445 SLEEVE 4110000054288
气缸套13056682 CYLINDER LINER 4110001525005
2 O型密封圈114*1.6 H2927 01153804 O-RING 4110000054002
3 O型密封圈116*4-NBR-1-60H2927 01153805 O-RING 4110000054003
4 碗形塞01152717 PLUG 4110000054297
5 凸轮轴衬套12159599 BUSHING 4110000054295
6 塞子290/s-8 12151365 PLUG 4110000054272
7 塞子290/-12 12273515 PLUG 4110000054270
8 凸轮轴衬套13032911 BUSHING 4110000846134
9 凸轮轴衬套13032912 BUSHING 4110000846135
10 双头螺柱90003813532 STUD 4110000924141
11 止推轴承盖（粗加工）12190135 COVER 4110001031050
11 主轴承螺栓13037380 SCREW 4110001948004
13 主轴承盖12188652 COVER 4110001948003
14 主轴承螺栓13037381 SCREW 4110001948005
15 组合密封垫圈 13023361 SEALING RING 4110000054337
16 弹簧垫圈Q40308 01177981 WASHER 4110000054023
17 O形密封圈01153869 O-RING 4110000054001
18 固定板50 DIN443 12160129 BRACKET 4110000054068
19 内六角圆柱头螺钉01151498 SCREW 4110000054198
20 焊接弯管20.3*24 H2927 12160117 INLET MANIFOLD 4110000054078
21 双头螺柱Q1200616 01151599 STUD 4110000054278
22 圆柱销13039669 PIN 4110000846147
23 双头螺柱M8*25-10.9 Zn DGB898 01153348 STUD 4110000054277
24 机体13034530 crankcase 4110001031001
25 套管13031278 THIMBLE 4110000846131
26 塞子290/-13 12273557 PLUG 4110000054271
27 螺杆9GB308 12167053 SCREW 4110000054185
28 球16JB982 01116958 BALL 4110000054246
29 帽形螺母12167057 NUT 4110000846024
30 弹簧BM14*135 DIN931-10.9 01221356 SPRING 4110000054019
弹簧垫圈Q40308 01177981 WASHER 4110000054023
2 六角头螺栓90011350088 SCREW 4110001525006
3 六角头螺栓13024408 SCREW 4110001525007
4 六角头螺Q150B0835 01139584 SCREW 4110000054144
5 六角头螺栓Q150B0845 01111151 SCREW 4110000054172
6 组合密封垫圈13023357 SEALING RING 4110000054335
7 齿轮端前墙盖分总成13050914 Gear housing cover assembly 4110000952001
1 前墙盖13039941 COVER 4110000991007
2 O型密封圈圈32*4-NBR-1-70H2927 06214722 O-RING 4110000054007
3 螺塞12165572 PLUG 4110000054145
4 密封圈40*4-NBR-1-60H2927 01161340 O-RING 4110000054008
5 呼吸器13031548 BREATHER CAP 4110000846061
6 密封垫圈A6-10-Cu-DIN7603 01118641 SEALING RING 4110000054194
7 六角头螺栓Q150B0690 01111096 SCREW 4110000054165
8 径向密封圈组件12188100 SEALING RING 4110000054100
9 内六角圆柱头螺钉01151462 SCREW 4110001031014
10 轴（前墙盖）12190581 SHAFT 4110000054015
11 六角头螺拴Q150B0820 01137083 SCREW 4110000054152
12 六角头螺栓Q150B0830 01112339 SCREW 4110000054170
13 六角头螺栓01112416 SCREW 4110000054156
14 盖13020237 COVER PLATE 4110000054060
1 六角头螺栓Q150B0816 01151569 SCREW 4110000054166
2 弹簧垫圈Q40308 01177981 WASHER 4110000054023
3 垫片13032177 SHIM 4110000846048
4 冷却油喷嘴组件13038438 SPRAY NOZZLE 4110001551041
5 O型密封圈01166001 O-RING 4110000054004
1 油路连接胶管13022800 HOSE 4110001525009
2 卡箍Q67535 12151665 CLAMP 4110000054262
3 油气分离器13037977 OIL-GAS SEPARATOR 4110000054311
4 垫圈 8 Q40108 01132562 WASHER 4110000560297
5 停用-I型六角螺母Q360B08 01112829 NUT 4110000054141
6 软管卡箍13039655 CLIP 4110000846125
7 弹簧12270389 SPRING 4110000054018
8 软管A18*24H7761 01396634 HOSE 4110000054299
9 六角头螺栓Q150B0830 01112339 SCREW 4110000054170
10 弹簧垫圈Q40308 01177981 WASHER 4110000054023
11 内六角圆柱头螺钉13026585 SCREW 4110001525008
12 停用-弹簧垫圈Q40312 01178366 WASHER 4110000054025
13 停用-平垫圈Q40110 01151002 WASHER 4110000991036
14 支架13024161 BRACKET 4110001031026
